Aquabotix Hydroview Sport Underwater Vehicle

$5,500.00

Hydroview Sport Highlights

  • Topside Box with LAN: Topside box with Ethernet Connector
  • Orientation Sensor: 3 axis attitude sensor (roll/pitch/yaw)
  • Depth Sensor: Provides depth of vehicle in water
  • Easy to use!

Description

HydroView SPORT Remote Operated Underwater Vehicle

The HydroView Sport is a remote controlled underwater vehicle that can record live video and capture photos in HD quality. Driving with our innovative iPad or laptop applications, you can fly the HydroView through the water viewing the live video feed as if you were under the water yourself. The HydroView, a mini remote operated vehicle (ROV), includes the following: LED lights, HD camera, Standard 75 foot cable, Waterproof carrying case, Topside box which generates its own Wi-Fi, free download of the application to use on your iPad, PC or MAC computer. The backpack sized HydroView can easily be stored on your boat or in a response vehicle. Its compact design also allows the vehicle to fit in small access locations.

*Why waste time and money to hire a diver when something under the water goes wrong? With this mini ROV, you can instantly inspect, evaluate and anticipate future problems you or your customers may encounter.

Standard Features

  • Topside Box with LAN: Topside box with Ethernet Connector
  • Orientation Sensor: 3 axis attitude sensor (roll/pitch/yaw) Compass heading with respect to true north
  • Depth Sensor: Provides depth of vehicle in water with 0.25 – % accuracy
  • Temperature Sensor:  – 0.2 degrees C, Tolerance -0.32%, 1 sec response
  • Propeller Covers: Guards vehicle propellers from debris

Inspect With Ease

Aquabotix HydroView Sport

HydroView MAX is the easiest ROV on the market to drive. Use the motion control feature on your iPad or keyboard controls on your laptop and the vehicle will respond in the appropriate direction. You can watch the HD video feed to perform inspections or explorations. Also, record the video to share with others or report important findings. In addition, there is no formal training required.

Pictures from HydroView

Pictures from HydroView

Pictures from HydroView

Pictures from HydroView

NOTE: 12V Topside Power Option allows for unlimited continuous power. There is no battery with this configuration so you will need 12V power to run the vehicle.

Additional information

Weight9.5 lbs
Dimensions19 × 14.6 × 7 in
Battery

Lithium, 15V 10.5 Ah; 2 Hours Run Time; 12 Hours Recharge Time

Motors

3 Swiss Made High Torque Motors; Precious Metal Magnets with 80% Efficiency

Color

Safety Orange and Black

Cable

200 ft (61 m); Black Thermoplastic Elastomer; Pressured 0.28 in. (5.77mm)

Speed / Battery Power

Up to 3 Knots (5.4 Km/h) forward; Up to 1 Knots (1.8 Km/h) reverse

Depth

150 ft. (45m)

Range

200 ft. (23 m) Cable

Vehicle Memory

32 GB High Speed

Camera

Wide Angle Full 1080p HD (1920×1080); 16:9 Aspect Ratio Widescreen; 130 degrees diagonal field of view; Automatic exposure control

Lights

10 LEDs – Cool White; 260000 mcd (80 Lumens); 6800K Dominant Wavelength; On/Off/Intensity controlled through App

Processor Board

Super-scalar ARM Cortex-A8 Processor at 1 GHz; Cortex C64X+ DSP Core; 512MB DDR Ram

Operating System

Embedded Linux
